| Standards | - IEEE 802.3
- IEEE 802.3u
- IEEE 802.3ab
- IEEE 802.3x
|
|---|
| Device Interface | - 8 x Gigabit ports
- 6-pin removable terminal block
- LED indicators
- DIN-Rail mount
- Wall mount
- Grounding point
|
|---|
| Data Transfer Rate | - Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
- Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
- Gigabit: 2000 Mbps (full duplex)
|
|---|
| Performance | - Data RAM Buffer: 128 KB
- Switching Fabric: 16 Gbps
- MAC Address Table: 8 K entries
- Forwarding rate: 11.9 Mpps (64-byte packet size)
|
|---|
| Special Features | - Hardened components rated for extreme temperatures
- Redundant power inputs
- Auto-Negotiation
- Auto store and forward architecture
- Automatic address learning and address aging
- ESD 8 kV and Surge 2 kV protection
|
|---|
| Power | - Input: 12 - 56 V DC
- Compatible power supply: TI-M6024 (sold separately)
- Consumption: Max. 5 Watts
|
|---|
| Terminal Block | - Redundant power inputs, alarm relay contact, 6 pin
- Wire range: 0.34 mm^2 to 2.5 mm^2
- Solid wire (AWG): 12-24/14-22
- Stranded wire (AWG): 12-24/14-22
- Torque: 5 lb. – In / 0.5 Nm / 0.56 Nm
- Wire strip length: 7-8 mm
|
|---|
| Alarm Relay Contact | - Relay outputs with current carrying capacity of 1 A, 24 V DC
- Open circuit mode when two power sources are connected
- Short circuit mode when only one power source is connected
|
|---|
| MTBF | |
|---|
| Housing | - IP30 metal case
- DIN-rail mount
- Wall mount
- Grounding point
- 8 kV ESD protection
- 2 kV surge protection
|
|---|
| Operating Temperature | |
|---|
| Operating Humidity | |
|---|
| Dimensions | |
|---|
| Weight | |
|---|
| Certifications | - CE
- FCC
- Shock (IEC 60068-2-27)
- Freefall (IEC 60068-2-32)
- Vibration (IEC 60068-2-6)
|
|---|
