Tehnilised andmed
Output
Max Configurable Power (Watts)
390 Watts / 620VA
Output Frequency (sync to mains)
50/60 Hz +/- 3 Hz Sync to mains
Topology
Line interactive
Waveform type
Stepped approximation to a sinewave
Transfer Time
2 ms typical
Input
Input frequency
50/60 Hz +/- 3 Hz Auto-sensing
Input voltage range for main operations
195 - 265V
Batteries & Runtime
Battery type
Lead-acid battery
Typical recharge time
5hour(s)
Nominal Battery Voltage
12 V
Replacement Battery
Expected Battery Life (years)
3 - 5
RBC Quantity
1
Battery Charge Power (Watts)
26 Watts
Runtime
Efficiency
Communications & Management
Interface Port(s)
DB-9 RS-232
Surge Protection and Filtering
Surge energy rating
320Joules
Data Line Protection
RJ45 modem/fax/DSL/10-100 base-T protection
Filtering
Full time multi-pole noise filtering : 0.7% IEEE surge let-through : zero clamping response time : meets UL 1449
Physical
Maximum Height
168MM, 16.8CM
Maximum Width
119MM, 11.9CM
Maximum Depth
375MM, 37.5CM
Net Weight
12.27KG
Shipping weight
13.18KG
Shipping Height
318MM, 31.8CM
Shipping Width
508MM, 50.8CM
Shipping Depth
262MM, 26.2CM
Color
Grey
Environmental
Operating Temperature
0 - 40 °C
Operating Relative Humidity
0 - 95 %
Operating Elevation
0 - 3048meters
Storage Temperature
-15 - 45 °C
Storage Relative Humidity
0 - 95 %
Storage Elevation
0 - 15240meters
Audible noise at 1 meter from surface of unit
45.0dBA
Online thermal dissipation
70.0BTU/hr
Conformance
Approvals
CE, EAC, GOST, VCCI, VDE
Standard warranty
2 years repair or replace
