Tehnilised andmed
| General | |
| Device Type: | Radio access point |
| Ruggedized Design: | Outdoor |
| Width: | 16.5 cm |
| Depth: | 16.5 cm |
| Height: | 11 cm |
| Weight: | 1.03 kg |
| Networking | |
| Form Factor: | External |
| Connectivity Technology: | Wireless |
| Data Transfer Rate: | 1.49 Gbps |
| Line Coding Format: | CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM, 1024 QAM, OFDMA |
| Data Link Protocol: | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, ZigBee, IEEE 802.11ac Wave 2, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6) |
| Spread Spectrum Method: | OFDM, DSSS, OFDMA |
| Frequency Band: | 2.4 GHz, 5 GHz |
| Performance: | Maximum data rate (5 GHz): 1.2 Gbps Maximum data rate (2.4 GHz): 574 Mbps |
| Capacity: | Wireless clients per Wi-Fi radio: 256 BSSIDs per radio: 16 OFDMA units: 16 |
| Status Indicators: | System, status, radio |
| Features: | Auto-uplink (auto MDI/MDI-X), Trusted Platform Module (TPM), reset button, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Virtual Mobility Controller mode, Advanced Cellular Coexistence (ACC), ClientMatch, cyclic shift diversity (CSD), MU-MIMO technology, packet aggregation A-MPDU, packet aggregation A-MSDU, Intelligent Power Monitoring (IPM), Dynamic Frequency Selection (DFS), High-Throughput (HT) support, Zero-touch provisioning (ZTP), Energy-Efficient Ethernet (EEE), waterproof, 2x2 MIMO technology, Very High Throughput (VHT) support, High Efficiency (HE) support, Target Wait Time (TWT), hardened, Wi-Fi 6 technology, Policy Enforcement Firewall (PEF), Layer 7 Deep Packet Inspection (DPI), Passpoint Release 2 |
| Encryption Algorithm: | WPA3-Enhanced Open, WPA2-MPSK |
| Aerial | |
| Antenna: | Internal |
| Directivity: | Omni-directional |
| Internet of Things (IoT) | |
| Internet of Things (IoT) Compatible: | Yes |
| Communications Technology: | Bluetooth Low Energy (LE), Zigbee |
| Expansion / Connectivity | |
| Interfaces: | 1 x 1000Base-T - RJ-45 2 x aerial 1 x console - USB-C |
| Miscellaneous | |
| Compliant Standards: | CB, UL 2043, FCC, EN 60601-1-2, cTUVus, IP67, IP66, EN 60601-1-1, EMC 2014/30/EU, LVD 2014/35/EU, ISED, IEC/EN/UL 60950, ETSI 300 019-2-4, RED 2014/53/EU |
| Pricing Type: | BTO |
| Power | |
| Power Over Ethernet (PoE) Supported: | PoE+ |
| Power Consumption Operational: | 15.6 watt |
| Software / System Requirements | |
| OS Required: | ArubaOS, InstantOS 8.8.0.0 |
| Environmental Parameters | |
| Min Operating Temperature: | -40 °C |
| Max Operating Temperature: | 55 °C |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
