Tehnilised andmed
https://www.hpe.com/psnow/doc/a00096366enw
| General | |
| Device Type: | Radio access point |
| Ruggedized Design: | Indoor |
| Width: | 8.6 cm |
| Depth: | 4.7 cm |
| Height: | 15 cm |
| Weight: | 360 g |
| Networking | |
| Form Factor: | External |
| Connectivity Technology: | Wireless |
| Data Transfer Rate: | 1.5 Gbps |
| Line Coding Format: | CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM |
| Data Link Protocol: | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
| Spread Spectrum Method: | OFDM, DSSS, OFDMA |
| Frequency Band: | 2.4 GHz, 5 GHz |
| Performance: | Maximum data rate (5 GHz): 1.2 Gbps Maximum data rate (2.4 GHz): 287 Mbps |
| Capacity: | Wireless clients per Wi-Fi radio: 256 BSSIDs per radio: 16 |
| Status Indicators: | Port status, power, system, status, PoE |
| Features: | Auto-uplink (auto MDI/MDI-X), DFS support, Wi-Fi Multimedia (WMM) support, 2T2R MIMO technology, packet aggregation A-MPDU, packet aggregation A-MSDU, HPE SmartRate |
| Encryption Algorithm: | WPA, WPA2, WPA3-Enterprise, Opportunistic Wireless Encryption (OWE), Simultaneous Authentication of Equals (SAE) |
| Compliant Standards: | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, Wi-Fi CERTIFIED, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az, IEEE 802.11ac, IEEE 802.3bz, IEEE 802.11ax |
| Aerial | |
| Antenna: | Internal |
| Antenna Qty: | 2 |
| Internet of Things (IoT) | |
| Internet of Things (IoT) Compatible: | Yes |
| Communications Technology: | Bluetooth Low Energy (LE), Zigbee |
| Expansion / Connectivity | |
| Interfaces: | 1 x 2500Base-T - RJ-45 1 x 1000Base-T - RJ-45 2 x 1000Base-T (PoE+) - RJ-45 1 x USB 2.0 - Type A 1 x console - micro-USB |
| Miscellaneous | |
| Compliant Standards: | EN 60950, IEC 60950, FCC, EN 60601-1-2, EN 60601-1-1, EMC 2014/30/EU, LVD 2014/35/EU, R&TTE Directive 1995/5/EC, ISED, RED 2014/53/EU |
| Power | |
| Power Over Ethernet (PoE) Supported: | PoE+ |
| Dimensions & Weight (Shipping) | |
| Shipping Width: | 11.1 cm |
| Shipping Depth: | 5.4 cm |
| Shipping Height: | 16.7 cm |
| Shipping Weight: | 450 g |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - lifetime |
| Environmental Parameters | |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 40 °C |
| Humidity Range Operating: | 5 - 93% (non-condensing) |
