KTI 7-port 10/100 L2 Fast Ethernet switch with 1 fiber connection
Hind ei sisalda käibemaksu.
Toode on tellitav.
Tehnilised andmed
| 10/100 Ports | IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX std. Shielded RJ-45 jacks with Auto MDI-X detection Auto-negotiation capable Speed for 10Mbps or 100Mbps Full-duplex or Half-duplex mode support |
| 100FX Port | IEEE 802.3u 100BASE-FX compliant, Fixed 100Mbps operation Duplex mode selector – Full-duplex or Half-duplex KS-105F-B – Far End Fault function |
| Flow control | IEEE 802.3x pause packet for Full-duplex operation Back-pressure for Half-duplex operation |
| Cables | 10Base-T: Cat. 3, 4, 5 or higher (100 meters max.) 100Base-TX: Cat. 5, 5e or higher (100 meters max.) 100Base-FX: Multimode or single mode fiber cable |
| LEDs | Power status Per port: Speed, Link, Activity, Duplex, Collision status |
| Forwarding rate | 14,880 pps for Ethernet (10M) 148,800 pps for Fast Ethernet (100M) |
| MAC Address Table | KS-105F-B: 2K entries KS-108F-B: 1K entries |
| Aging time | KS-105F-B: 280 seconds KS-108F-B: 240 seconds |
| Environment | Operating Temperature: 0°C ~ 40°C (Main device) Storage Temperature: -40°C ~ 85°C Relative Humidity: 10% ~ 90% non-condensing ( The operating temperature range of the bundled power adapter may differ from the temperature range of the main device.) |
| Dimensions | KS-105F-B: 144 x 104.5 x 26 mm (WxDxH) KS-108F-B: 180 x 114.5 x 26 mm (WxDxH) |
| Power Input | +5V ~ +12VDC (+/-5%) via external power adapter |
| Power Consumption | KS-105F-B: 3W max. @+5V (DC IN) KS-108F-B: 3.5W max. @+5V (DC IN) |
