Tehnilised andmed
https://www.corsair.com/eu/en/p/psu/cp-9020271-eu/rmx-series-rm1000x-fully-modular-power-supply-eu-cp-9020271-eu
| General | |
| Device Type: | Power supply - internal |
| Specification Compliance: | ATX12V 3.1/ EPS12V |
| PSU Form Factor: | ATX |
| Localisation: | Europe |
| Power Device | |
| Input Voltage: | AC 100-240 V |
| Frequency Required: | 47 - 63 Hz |
| Power Output Connectors Details: | 1 x power 24 pin ATX 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section 4 x 8 pin PCI Express power with detachable 2 pin section 12 x 15 pin Serial ATA power 6 x 4 PIN internal power 1 x 16 pin PCI Express power |
| Output Voltage: | +3.3, +5, +12 V, +5Vsb V |
| Power Capacity: | 1000 Watt |
| Output Current: | +3.3V - 20 A +5V - 20 A +12V - 83.3 A +5VSB - 3 A |
| Modular Cable Management: | Yes |
| Cybenetics Certification: | Cybenetics Gold |
| Miscellaneous | |
| Cables Included: | AC power cable Power 24 pin ATX with detachable 4 pin section modular cable 61 cm 2 x power 8 pin EPS12V modular cable 75 cm 4 x 8 pin PCI Express power with detachable 2 pin section 65 cm 16-pin 12VHPWR power modular cable 65 cm 3 x 15 pin Serial ATA power modular cable 85 cm 2 x 4 pin power modular cable 75 cm |
| MTBF: | 100,000 hours |
| Cooling System: | 140 mm fan |
| Features: | Zero RPM fan mode, manual fan speed control, fully modular, Cybenetics A, Modern Standby compatible |
| Compliant Standards: | UKCA, RoHS |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - 10 years |
| Dimensions & Weight | |
| Width: | 15 cm |
| Depth: | 16 cm |
| Height: | 8.6 cm |
| Weight: | 3.65 kg |
