| Package height [mm]: | 223 |
| Package width [mm]: | 372 |
| Depth / Length of package [mm]: | 141 |
| Package contents: | - UPS with built-in power cable (1 x SCHUKO type E) 1.15 m - User manual |
| Dimensions (D/L x W x H): | 320x90x142mm |
| Operating temperature: | 0˚C ~ +40˚C |
| Housing color: | Black |
| Comments: | Network emergency power supplies designed for telecommunications equipment and automatic data processing equipment, the so-called uninterruptible power supply UPS. In the event of a power failure, it provides a "reserve" of energy, thus protecting against loss |
| Net weight [kg]: | 4.2 |
| Gross weight [kg]: | 5.4 |
| Certificate: | CE |
| Guarantee: | 24 months |
| Additional information: | - output voltage in wired mode: 220 VAC ± 10% (50 Hz - 60 Hz ± 1 Hz) |
| Security: | - Overload protection - Short circuit protection - High temperature protection - High/low voltage protection - Input fuse protection |
| Output frequency: | 50Hz - 60Hz ± 1Hz |
| Input frequency range: | 50Hz ± 5Hz |
| Output voltage: | 220VAC ~ 230VAC ± 5% |
| Input voltage: | 140VAC ~ 290VAC |
| Rated power: | 600VA |
| Power: | 360W |
| Waveform: | Modified sine wave |
| UPS type: | Line Interactive |
| Built-in battery: | Yes |
| Number of batteries: | 1 |
| Battery voltage: | 12V |
| Noise level: | <40dB |
| Application: | Data processing centers; industrial and manufacturing environments; medical centers |
| Display: | LCD |
| Communication system: | USB |
| Output sockets: | 1 x FRENCH (Type E CEE 7/5) 1 x SCHUKO (Type F CEE 7/3) 1 x USB type B (port for device diagnostics) 2 x RJ45 |
| Transfer time: | 2 - 6 ms |
| Charging time: | 6h to 90% capacity |
| Battery capacity: | 7Ah |
